Empowering Your Dental Laboratory
Super Opacity Zirconia
Super Strength
AZR O is a dental zirconium oxide (3Y-TZP) with very high flexural strength (1350 MPa) for the fabrication of single tooth up to multi-unit bridge frameworks.
The high opacity value (35% translucency) provides optimum optical properties for discolored stumps and metal posts and cores. The special production procedure for the discs improves the milling properties and results in excellent accuracy of fit and high edge stability.
 |
 |
 |
 |
 |
|
Type |
Flexural strength |
Translucency |
Indications |
Processing techniques |
| 3Y-TZP | 1350 MPa | 35% |
Single-unit restorations up to multi-unit bridges |
Infiltration technique Staining technique Cut-back technique |
Processing Options
Copings for full anatomical or partial veneering
Brush and/or dipping infiltration
Indications
l Single-tooth restorations ( posterior)
l 3-unit bridges (posterior)
l Multi-unit bridges (posterior)
Delivery forms
l 98mm white (10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 22mm, 25mm 30mm)
l 71mm white (10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 22mm, 25mm, 30mm)
l 95mm white (10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 22mm, 25mm, 30mm)
Packaging
Single Disc
Our Advantage:
Wide compatibility
Thickness ranges from 10mm,12mm,14mm,16mm,18mm,20mm,22mm
and 25mm.Compatible with Roland,Wieland,VHF,Amann Girrbach,Yenadent and
other most open CAD CAM milling machines.
Cold isostatic pressing
All of our blocks are isostatically pressed to ensure uniform shrinkage and density by the sintering process.
Work with Tosoh zirconia powder
We can keep a good quality know-how in powder comparable with Tosoh, while keeping cost competitive and most fine powder from China, due to their high-ranking properties for purity and quality to make our disks the best they can be.
100% safe every time
Our Zirconia blanks are allergen-free and bio-inert. It will not transmit heat or cold from the mouth to the surrounding bone. You can use it confidently and safely.
Take care of your mill
WallaBC zirconia pucks are softer than the generic zirconia. Which can well take care of your spindle and other milling tools, you can use them much longer.
Technical Data
Specifications
Complete material and geometry data for the AZR O disc series.
| Material Type | 3Y-TZP (3 mol% yttria-stabilized tetragonal zirconia) |
| Flexural Strength | 1350 MPa |
| Translucency | 35% |
| Indications | Single-tooth restorations (posterior), 3-unit bridges, and multi-unit bridge frameworks (posterior) |
| Colors | White blank — supports full VITA 16 classical shade customization via pre-sintering liquids |
| Geometries | W-98mm · Z-95mm · D-71mm |
| Thicknesses | 10 / 12 / 14 / 16 / 18 / 20 / 22 / 25 / 30 mm |
| Compatible Systems | Roland · Zirkonzahn · VHF · IMES-iCore · Arum · Wieland · Sirona CEREC · Dentium · UP3D · and more |
| Shading Method | Pre-sintering staining liquid (full VITA 16 color range) |
Color Options
VITA 16 Shades
All 16 VITA Classical shades supported via pre-sintering liquids — precise, repeatable, and consistent every time.
A Series
A1
A2
A3
A3.5
A4
B Series
B1
B2
B3
B4
C Series
C1
C2
C3
C4
D Series
D2
D3
D4
Indication Guide
AZR O — Suitable Applications
Star ratings indicate suitability for each indication. Five stars = ideal; fewer stars = usable but other materials may be preferred.
Rating Scale
★★★★★
Ideal
★★★★★
Excellent
★★★★★
Good
★★★★★
Acceptable
★★★★★
Limited
Veneers
Thin anterior facings
★★★★★
Limited
Inlays / Onlays
Conservative posterior restorations
★★★★★
Good
3-Unit Bridge
Full-contour fixed bridge
★★★★★
Ideal
Full-Contour Crown — Anterior
Monolithic anterior tooth crown
★★★★★
Good
Full-Contour Crown — Posterior
Monolithic posterior tooth crown
★★★★★
Ideal
Hybrid Abutment Crown
Implant-supported hybrid restoration
★★★★★
Ideal
Long-Span Bridge
Extended multi-unit bridge framework
★★★★★
Ideal
Full-Arch Framework
Implant-supported full-arch reconstruction
★★★★★
Ideal
Price List (USD)
AZR O Pricing
Transparent, competitive pricing across all geometries and thicknesses — with generous volume discounts for high-output labs.
W-98mm
| Thickness | Price |
|---|---|
| 10mm | $29.00 |
| 12mm | $32.00 |
| 14mm | $35.00 |
| 16mm Popular | $37.00 |
| 18mm | $40.00 |
| 20mm | $43.00 |
| 22mm | $49.00 |
| 25mm | $55.00 |
| 30mm | $62.00 |
Z-95mm
| Thickness | Price |
|---|---|
| 12mm | $32.00 |
| 14mm | $35.00 |
| 16mm Popular | $37.00 |
| 18mm | $40.00 |
| 20mm | $43.00 |
| 22mm | $49.00 |
| 25mm | $55.00 |
| 30mm | $62.00 |
D-71mm
| Thickness | Price |
|---|---|
| 10mm | $29.00 |
| 12mm | $32.00 |
| 14mm | $35.00 |
| 16mm Popular | $37.00 |
| 18mm | $40.00 |
| 20mm | $43.00 |
| 22mm | $49.00 |
| 25mm | $55.00 |
| 30mm | $62.00 |
Volume Discounts
5+ Pieces
Minimum order for discount
10%
OFF list price
10+ Pieces
Best value for high-output labs
20%
OFF list price
Shipping & Policy
Free standard shipping on orders over $99
Ships within 5–7 business days
30-day hassle-free returns
Express: 3–10 days via UPS / DHL / FedEx
Sintering Parameters
AZR-O Sintering Curves
All parameters listed are recommendations. Actual temperatures vary by furnace — verify with PTC rings. An opaque result may indicate incorrect furnace temperature.
Factors Affecting Quality
Firing capacity and chamber volume of the furnace
Size and volume of each individual construction
Total mass in firing chamber (sintering media + quantity of constructions)
General Rule
A slower sintering cycle improves zirconia structure quality. Bridges need longer uniform heat distribution — rapid heating can cause warping or cracking, especially in long-span bridges.
⚠ Important
Do not load the furnace when residual temperature exceeds 70°C — danger of thermal shock.
⚠ Important
Never open the furnace door above 300°C — thermal shock can damage heating elements and restorations.
1–3 Units
4–6 Units
≥ 7 Units
Temperature Curve (°C over time)
Ramp
Hold
Cool
| Phase | Temp Range (°C) | Rate (°C/min) | Hold (min) |
|---|
